y left entirely clear. The inner column should be of sufficient strength to alonesustain the weight to be imposed. In connecting and resting an upper on a lower column, a,plate should be placed between the two as shown at Fig. 2 ; a CAST-IRON COLUMNS. 59 floor beam or girder also being shown below… … a f-inch-thick shell being as light a column (over 9 inches indiameter) that should be cast for supporting any weight. . 108. Dowel Columns.—For buildings where the floor beamsand girders are of wood, the columns for their support are castas shown. The portion of column at girder is cast similar to…
