Common objects of the microscope [electronic resource] (1900)
Wood, J. G. (John George), 1827-1889, West, Tuffen, ill, Bousfield, E. C. (Edward Collins), b. 1855 · London : G. Routledge & Sons · leaf 30
REAL IMAGE image will bo situated along the lines AB, BArespectively. Moreover, rays pass from every partof the object to every part of the lens, so that womust imagine the cones LAL, LAL to be filledwith rays diverging on one side of the lens andconverging on the other. The image so formed is a… … Fro. 3. object placed nearer to the lens than the principalfocal length of the latter, so that the rays diverge,instead of converging, as they leave the lens, and theeye looks, as it were, back along the path in whichthe rays appear to travel, and so sees an enlargedimage situated in the air,…
Microscopy
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
![An illustration from Common objects of the microscope [electronic resource], 1900, leaf 30](https://img.insideoutlibrary.com/img/1024/ia-49492157.2969.emory.edu-30-13.webp)
