Section Thru Sill—Warranted Proof Even Against DrivingRain. Note That Standard Flush Bolt Requires Sill Rabbet tobe at Least % Inch. … Sash opjcn: 90 bcgrees. Section Thru Window Jamb, Flush with Plaster.
