A standard hydraulic slide-valve is illustrated by the►Section No. 3. The lower portion is in gun-metal, with ahard seat sweated and pinned on ; while the top portionis in cast iron. For low and medium pressures this typeis satisfactory. The elevation and section No. 4 illustrate a… … No. 3.—Standard Slide Valve. Open toJ rhaiust
