WALU 15 Six patiel Q-ueen Truss for deck roof. Timbers in compression, rods in tension.Spans 40 to 52 feet. Ceilint^ may be carried on lower chord. <-C^STlN& PRlPlClPAL DRIpT BOLT ~i kfnJRLIN … No. 43 WALLWALL Combination timber and iron Truss for pitch roof used where no ceiling is constructed.Spans up to 40 feet. Timbers in compression, rods in tension. F^OOF-
