Detrick arches showing their adaptability to all types of boilers and stokers, special furnaces and oil stills (1921)

M.H. Detrick Company. · M.H. Detrick Co. · leaf 24

An illustration from Detrick arches showing their adaptability to all types of boilers and stokers, special furnaces and oil stills, 1921, leaf 24 — ARCHES Vogt Boiler and Laclede-Christy Stoker ShowingFirst Tile Lowered toProtect the Stoker Gate … IIIIIIIHIII Page Twenty-three DETRICR

Building materials · Masonry · Refractory masonry · Flat arch
