Detrick arches showing their adaptability to all types of boilers and stokers, special furnaces and oil stills (1921)

M.H. Detrick Company. · M.H. Detrick Co. · leaf 39

An illustration from Detrick arches showing their adaptability to all types of boilers and stokers, special furnaces and oil stills, 1921, leaf 39 — lllllllllllllllllllllllllllllllllllllllllllll Page Thirty-seven DETRICK … ARCHES Plan and Section of ArchInstallation Over a LargeDutch Oven and Super-Heater Used in Oil Refin-eriesNote Large Area Coveredby Arch

Building materials · Masonry · Refractory masonry · Flat arch
