Practical electricity, with questions and answers (1901)
Cleveland armature works, [from old catalog] comp, Lincoln, John C. [from old catalog] · [Cleveland, Ohio, Cleveland armature works] · leaf 146
airmature issubjected will not affect it. In practice the discs for arma-tures run from ten to twenty-five thousandths of an inch inthickness. Even in the thinnest disc there are small eddycurrents circulating which take power to produce and whichheat 1he armature core. The loss by eddy currents… … Figure 51 Circulation of eddy currents ©topped by lamination of the iron. 134 Formula S shows that the loss in watts with doublevolts and double current is four times as great as with thegiven voltage. It is because of the loss by eddy currentsthat would occur with solid pole pieces that pole…Electricity · Electric generators
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
