Grey, C. G. (Charles Grey), 1875-1953 · London, "The Aero" · leaf 12
I. Single plane front damper. 2. Vertical planes to give directional senseand lateral stability. 3. Upper naain plane. 4. Lower main plane. 5. Body.6. Upper horizontal tail plane. 7. Lower horizontal tail plane. 8. Vertical tailplanes. 9. Rudder, in middle of tail. 10. Main landing wheels. 11.… … I. Main plane, shaped like the two wings of a bird if joined together at the^roots.2. Tilted tips, to give directional sense and lateral stability. 3. Ailerons, forsteering combined with lateral stability in turning. 4. Propellers. 5. Bodyfor driver. 6. Landing wheels. (3) THE HOWARD WRIGHT BIPLANE.
Airplanes
