Common-sense stair building and handrailing (1903)

Fred T Hodgson · Frederick J. Drake and Co. · leaf 118

An illustration from Common-sense stair building and handrailing, 1903, leaf 118 — n4 COMMON-SENSE HANDRAILING upper section shows the rail, which is supposed to bethe full size; the lower section shows the cap^ whichmay be of any reasonable diameter. Draw the plan ofthe cap as shown, then a section of the rail, then draw

Wood stairs and railings · Woodwork · Architecture, Domestic · Designs and plans

Internet Archive · Building Technology Heritage Library · Public Domain Mark 1.0. Free to use for anything.
