he carriage pieces, as the latter should, whenpossible, fit snug to both tread and riser and go wellinto the angles. Sometimes i nlanding stairs therail finishes in acap at the top ofthe newel; in suchcases, the cap isturned, having itsedge made in thesame shape as theedge or mouldingof the rail,… … Fig. 7. 114 COMMON-SENSE HANDRAILTNG upper section shows the rail, which is supposed to bethe full size; the lower section shows the cap, whichmay be of any reasonable diameter. Draw the plan ofthe cap as shown, then a section of the rail, then draw
