ted ordinates AA tomark center of curve and chord line. The spring bevel for squaring the wreathat lower end is found at angle E. To obtain the bevelfor upper joints take a center anywhere on line ED,describe an arc touching EG and cutting ED at H.Draw line from center of arc at right angles to ED,…
