Common-sense stair building and handrailing (1903)
Fred T Hodgson · Frederick J. Drake and Co. · leaf 42
attached will give a clear insightinto the method of lining out the present examples. The next examples show a method of laying downthe rail for a flight of circular stairs. Fig. 48 showsthe plan with cylinder and risers cutting around thecenter of rail and tangents. The joints are located atA, B,…
Wood stairs and railings · Woodwork · Architecture, Domestic · Designs and plans
Internet Archive · Building Technology Heritage Library · Public Domain Mark 1.0. Free to use for anything.
