Illustrated catalogue of galvanized iron roofing and shedding, iron structures, &c. : patent portable steel railways, railway plant, iron bridges, &c. (1884)

A. & J. Main & Co. · A. & J. Main & Co. · leaf 6

An illustration from Illustrated catalogue of galvanized iron roofing and shedding, iron structures, &c. : patent portable steel railways, railway plant, iron bridges, &c., 1884, leaf 6
SECTION No. 2—Suitable for Spans of 35 to 50 feet, shewing Curved Ventilator on Apex, which can be applied to any of the Sections. … SECTION No. 3.—Suitable for Spans of 50 to 70 feet.

Roofing · Sheet roofing · Corrugated roofing · Sheet metal · Structural iron · Ironwork

Internet Archive · Building Technology Heritage Library · Public Domain Mark 1.0. Free to use for anything.
