Effect of orifice length-diameter ratio on the coefficient of discharge of fuel-injection nozzles (1931)
NASA Technical Reports Server (NTRS) · leaf 16
N,A.C.At Technical Note Ho* 369 Automatic injection valve Adapter (A) Nozzle assembly with plain stem Enlarged view of nozzle assembly with helically-grooved stem (0) Nozzle assembly straight passage Fig- 1 Hozzle assembliesNASA Technical Reports Server (NTRS)
Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
