Wind tunnel research comparing lateral control devices, particularly at high angles of attack XI : various floating tip ailerons on both rectangular and tapered wings (1933)

NASA Technical Reports Server (NTRS) · leaf 32

An illustration from Wind tunnel research comparing lateral control devices, particularly at high angles of attack XI : various floating tip ailerons on both rectangular and tapered wings, 1933, leaf 32 — H.A.C.A. Technical llote Uo. 458 ffig. 5

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
