28 COURSE IN WOODEN BOAT AND SHIP BUILDING … STEM AND STERN CONSTRUCTION 29 the deck, and forms a receptacle for the after endsof the outside planking. Stern Post Knee.—The stern post knee is placedin the angle formed by the keel and stern post. Shaft Log.—The shaft log is the member of thestern through which the propeller shaft enters.…
