Simplified aerodynamic analysis of the cyclogiro rotating wing system (1930)

NASA Technical Reports Server (NTRS) · leaf 15

An illustration from Simplified aerodynamic analysis of the cyclogiro rotating wing system, 1930, leaf 15 — tf.A.C.A. Technical ITote lTo.467 Figs. 2,3 … Figure 3.-Velocity diagram.

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
