The N.A.C.A. Optical Engine Indicator (1938)
NASA Technical Reports Server (NTRS) · leaf 11
Section B-B. Enlarged Figure 3, - Details of high-temperature diaphragm unit.NASA Technical Reports Server (NTRS)
Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
