High velocity wind tunnels : their application to ballistics, aerodynamics, and aeronautics (1925)

NASA Technical Reports Server (NTRS) · leaf 32

An illustration from High velocity wind tunnels : their application to ballistics, aerodynamics, and aeronautics, 1925, leaf 32
N.A.C.A. Technical Memorandum No.318 Figs.5 & 6. .40 .30 f(v) .20 .10 0 500 lOOO V (m/sec.) f (v) of the Gavre Com. f (v) Theoretical law f (v) Law of Siacci f (v) for spherical "bullets Fig.5 Curves of the function f(v).
