Spray Penetration with a Simple Fuel Injection Nozzle (1926)
NASA Technical Reports Server (NTRS) · leaf 6
i Fig. 3.—Injection pressure, 3,000 lb./sq. in. Chamber pressure, atmospheric … Fig. 4.—Injection pressure, 3,000 lb./sq. in. Chamber pressure, 100 lb./sq. in. Fig. 5.—Injection pressure, 3,000 lb./sq. in. Chamber pressure, 200 lb./sq. in. The original photographs for Figures 3 to 8 inclusive were retouched for reproduction purposes 51173—27 2
