Drag and Cooling with Various Forms of Cowling for a "Whirlwind" Radial Air-Cooled Engine I (1930)

NASA Technical Reports Server (NTRS) · leaf 22

An illustration from Drag and Cooling with Various Forms of Cowling for a "Whirlwind" Radial Air-Cooled Engine I, 1930, leaf 22
DRAG AND COOLING A ''WHIRLWIND'' RADIAL AIR-COOLED ENGINE—I … Figure 20 —Cowling No. 8, original

NASA Technical Reports Server (NTRS)

Internet Archive · NASA Technical Reports · Public domain (US government work). Free to use for anything.
