roof plan, first and second floorplans; front, right, left and rear elevations; wall sections and all necessary details. The Typewritten Specifications contain all the necessary information for the proper construction of the House. Design No. 7054 Size: Width, 38 feet; Lrength, 36 feet 6 inches,… … /5 J. □ Blue prints consist ofbasement plan; roof plan;first and second floorplans; front, rear, twoside elevations; wall sec-tions and all necessaryinterior details. Specifi-cations consist of abouttwenty pages of type-written matter.
