The A B C of vacuum tubes in radio reception; an elementary and practical book on the theory and operation of vacuum tubes as detectors and amplifiers. Explains non-mathematically the fundamental principles upon which all vacuum tube circuits are based. Includes practical circuits and practical questions and answers. It is written especially for the beginner. All electrical and radio terms are fully explained (1922)

Lewis, Elmer Hugh, 1889- · New York, Norman W. Henley Pub. Co. · leaf 49

An illustration from The A B C of vacuum tubes in radio reception; an elementary and practical book on the theory and operation of vacuum tubes as detectors and amplifiers. Explains non-mathematically the fundamental principles upon which all vacuum tube circuits are based. Includes practical circuits and practical questions and answers. It is written especially for the beginner. All electrical and radio terms are fully explained, 1922, leaf 49
Plate + <\Pos … Plate ~=~ Battery-§Neg. Current IndicatingDevice Fig. 15—One method of varying the grid potential. flow in the grid circuit, from grid to filament inside the tube.This grid current also increases, up to a certain point, with theincrease in positive grid potential. If a negative potential is applied…
