Greene, Charles E[zra] 1842- [from old catalog], Greene, Albert Emerson. [from old catalog] · Ann Arbor, Mich., Printed for the author · leaf 109
ral axis of the bent beam at anypoint, and its deflection, or perpendicular displacement, atany point from its original straight line, or from a given axis.102. Formula for Curvature.—If, through the pointsA and B, on the neutral axis of a bent beam. Fig. 50, anddistant ds apart, normals C D and K… … DEFLECTION OF SIMPLE BEAMS. 97 K G, the distance F C will be the elongation, or H D will bethe shortening, from the unit stress f, of the extreme fibrewhich was ds long before flexure. Cross-sections planebefore flexure are plane after flexure, § 75. /A O = p, A C = _yi; C F = — ^i, § 10. From…
Mechanics, Applied · Strength of materials
