Greene, Charles E[zra] 1842- [from old catalog], Greene, Albert Emerson. [from old catalog] · Ann Arbor, Mich., Printed for the author · leaf 206
e ellipse of stress).Thus is found O R or — O R as the case may be. DrawR R and, since R M R must be an isosceles triangle, bisectR R at T and drop a perpendicular to R R from T on to thenormal, cutting the latter at M. Then since, as previouslypointed out, O M = ^{p, -f p.,) and M R = M R =i (pi —… … »i&74. 2 M O X of Fig. 73, the direction of the axis X along which/i acts will bisect N M R, and the axis along which p^ actswill be perpendicular to axis X. They may be now at oncedrawn through O, if desired. 194. From any two Stresses to find other Stresses.—From the preceding construction, §…
Mechanics, Applied · Strength of materials
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
