Fig. 110. Fig. hi. … Live Load Stresses.—The stresses in the chords and in 1-2 and 2-3 are a maximum forfull load, and may therefore be obtained by multiplying the corresponding dead load stresses hv 18 0 0 For a maximum in 3-4 and 4-5, all joints up to 5 should be loaded. The reaction ispd then equal to ^(i + 2 +…
