Pomilio, Ottorino · New York, McGraw-Hill · leaf 36
t, producinga reaction whose direction is upward or downward respec-tively, thus tending to set the machine for climbing ordescending. The size of the elevator also depends on the weight,moment of inertia, speed of the machine, and on its dis- THE CONTROL SURFACES 21 tance from the center of… … Fig. 23. for slow machines endowed with a greater degree of stabil-ity. In other words, the two proportions vary inverselyas those of the stabiUzers. However, this will bemore easily understood upon considering the functions of 22 AIRPLANE DESIGN AND CONSTRUCTION the two devices which are in a…
Airplanes
Internet Archive · Public Domain Mark 1.0. Free to use for anything.
