Pomilio, Ottorino · New York, McGraw-Hill · leaf 51
BALANCED RUDDERI A … Fig. 37. oted on a universal joint, moved forward and backward tolower and raise the elevator, and from left to right to movethe ailerons (Figs. 35 and 36). Balanced rudders are found on some of the high-poweredmachines, as they reduce, to a slight degree, the musculareffort of the pilot. The…
Airplanes
