Amateur mechanics ... a book for old and young who like to make things .. (1907)
Popular mechanics magazine, Chicago. [from old catalog] · Chicago, Popular mechanics · leaf 56
etweenthe two screws shown in Fig. 2. Theends of this small axle should be groundpointed and should turn easily in thecavities, as the sensitiveness of the in-strument depends on the ease withwhich this axle turns. After assembling the core as shownin Fig. 4, it should be filed a little atone end… … Fig. 2 Complete Ammeter and Details sary is that of leveling, which is ac-complished by turning the thumbscrew shown Wig. 1, until the hand points to 0 on the scale. First make a support. Fig. 2.bending a piece of sheet brass to theshape indicated and tapping for thescrews, C C. These should have…
