Mechanics of engineering. Comprising statics and dynamics of solids: and the mechanics of the materials of constructions, or strength and elasticity of beams, columns, arches, shafts, etc (1888)
Church, Irving P[orter], 1851- [from old catalog] · New York, J. Wiley & sons · leaf 396
,between two vertical sections at a distance apart= liY =the height of the web. In such a beam under forces L *°its axis it has been proved (§256) that we may considerthe web to sustain all the shear, J, at any section, and theflanges to take all the tension and compression, whichform the… … Fig. 1)23 equal. N-ow the shear acting between each flange and thehorizontal edge of the web is equal in intensity per squareinch to that in the vertical edge of the web; hence if theweb alone, of Fig. 323, is shown as a free body in Fig. 324,we must insert two horizontal forces = J, in opposite…
Mechanics, Applied · Engineering · Strength of materials
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
