The American house-carpenter; a treatise on the art of building, and the strength of materials (1873)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York : J. Wiley · leaf 306
Fig. 250. equal to c 4 in the previous figure, and c s equal to c s also in theprevious figure; then describe the inner edge of the board, H,according to Art. 87 : the outer edge can be obtained by gaugingfrom the inner edge. In like manner proceed to obtain the nextboard—taking p 5 for half the… … 398.— To find the shape of the angle-rib for a polygonaldcme. Let A G H, (Fig. 251,) be the plan of a given dome, and 292 AMERICAN HOUSE-CARPENTER. C D a vertical section taken at the line, ef. From 1, 2, 3, &c.in the arc, C D, draw ordinates, parallel to A Z>, to meet/ G ,from the points of…
Carpentry · Architecture
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
