ce-mouldsover winders, are intended for moulded rails. For round rails,the same process is to be followed with this difference: insteadof working from the sides of the rail, work from a centre-line.After finding the projection of that line upon the upper plane,describe circles upon it, as at Fig.… … 880 AMERICAN HOUSE-CARPENTER 497.—To ascertain the form of the newel-cap from a sectionof the rail. Draw-a b, (Fig. 333,) through the widest part oftke given section, and parallel to c d; bisect a b in e, and througha, e and &, draw h i,fg, and k j, at right angles to a 6 ; at a con-venient…
