The American house-carpenter; a treatise on the art of building, and the strength of materials (1873)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York : J. Wiley · leaf 52
Fie. 64. 99.—To construct a triangle whose sides shall be severallyequal to three given lines. Let a, b and <?, (Fig. 64,) be the givenlines. Draw the line, d e, and make it equal to c ; upon 0, withI for radius, describe an arc at f • upon d, with a for radius,describe an arc intersecting the… … Fig. 65. Fig. 66. 38 PRACTICAL GEOMETRY. 100.— To construct a fgure equal to a g.ven, right-linedfigure. Let a b c d,(Fig. 65,) be the given figure. Make e/,(Fig. 66,) equal to c d ; upon /, with d a for radius, describe anarc at g; upon e, with c a for radius, describe an arc intersectingthe other…
Carpentry · Architecture
Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
