The American house carpenter. A treatise on the art of building. Comprising styles of architecture, strength of materials, and the theory and practice of the construction of floors, framed girders, roof trusses, rolled-iron beams, tubular-iron girders, cast-iron girders, stairs, doors, windows, mouldings, and cornices; together with a compend of mathematics. A manual for the practical use of architects, carpenters, stair-builders, and others (1880)

Hatfield, R. G. (Robert Griffith), 1815-1879, Hatfield, O. P., ed · New York, J. Wiley & sons · leaf 299

An illustration from The American house carpenter. A treatise on the art of building. Comprising styles of architecture, strength of materials, and the theory and practice of the construction of floors, framed girders, roof trusses, rolled-iron beams, tubular-iron girders, cast-iron girders, stairs, doors, windows, mouldings, and cornices; together with a compend of mathematics. A manual for the practical use of architects, carpenters, stair-builders, and others, 1880, leaf 299
©toHqiic Plane.— A prism isshown in perspective at Fig. 139, cut by an oblique plane.The points abed are the angles of the horizontal base, andabg, bef, edef, and adeg are the vertical sides; while^f^S is the top, the form of which is to be shown. 267.—Form of Top of Prism—In Fig. 139 the form… … Fig. 139. and size of the base, abed, of the prism shown in Fig, 139.Make c, and dd^ respectively equal to the actual heights at .4
