The American house carpenter. A treatise on the art of building. Comprising styles of architecture, strength of materials, and the theory and practice of the construction of floors, framed girders, roof trusses, rolled-iron beams, tubular-iron girders, cast-iron girders, stairs, doors, windows, mouldings, and cornices; together with a compend of mathematics. A manual for the practical use of architects, carpenters, stair-builders, and others (1880)
Hatfield, R. G. (Robert Griffith), 1815-1879, Hatfield, O. P., ed · New York, J. Wiley & sons · leaf 372
Fig. 208. Fig. 209. drawn from <^, as at <^; and that will be the centre of thecurve. In a similar manner, the centres are found for themouldings at Figs. 207,211, 213, 216, 217, 218, and 219. Thecentres for the curves at Figs. 220 and 221 are found thus:bisect the line ^ ^ at ^; upon a, c…
Carpentry · Architecture · Building
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
