The American house carpenter. A treatise on the art of building. Comprising styles of architecture, strength of materials, and the theory and practice of the construction of floors, framed girders, roof trusses, rolled-iron beams, tubular-iron girders, cast-iron girders, stairs, doors, windows, mouldings, and cornices; together with a compend of mathematics. A manual for the practical use of architects, carpenters, stair-builders, and others (1880)
Hatfield, R. G. (Robert Griffith), 1815-1879, Hatfield, O. P., ed · New York, J. Wiley & sons · leaf 44
^^iiiiiiiiiiiE:: aiiiiiiiii FA^XIFUL ORICIX OF THE DORIC. 17 Grecians. These no doubt were very rude, and perhapsnot unhke the following figure. … Fig. I.—Supposed Origin of Doric Temple. The trunks of trees, set perpendicularly to support theroof, may be taken for columns ; the tree laid upon thetops of the perpendicular ones, the architrave ; the endsof the cross-beams which rest upon the architrave, thetriglyphs ; the tree laid on the…
Carpentry · Architecture · Building
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
