The American house carpenter. A treatise on the art of building. Comprising styles of architecture, strength of materials, and the theory and practice of the construction of floors, framed girders, roof trusses, rolled-iron beams, tubular-iron girders, cast-iron girders, stairs, doors, windows, mouldings, and cornices; together with a compend of mathematics. A manual for the practical use of architects, carpenters, stair-builders, and others (1880)

Hatfield, R. G. (Robert Griffith), 1815-1879, Hatfield, O. P., ed · New York, J. Wiley & sons · leaf 652

An illustration from The American house carpenter. A treatise on the art of building. Comprising styles of architecture, strength of materials, and the theory and practice of the construction of floors, framed girders, roof trusses, rolled-iron beams, tubular-iron girders, cast-iron girders, stairs, doors, windows, mouldings, and cornices; together with a compend of mathematics. A manual for the practical use of architects, carpenters, stair-builders, and others, 1880, leaf 652
and hs\ then the limit of the shadow will becompleted. 580.—To Find the Shadow Thrown by a Pedestal uponSteps.—From a {Fig. 442) in the plan, and from c in the ele-vation, draw the rays ab and ce; then ao Avill show the ex- SHADOWS ON STEPS AND COLUxMNS. 607 tent of the shadow on the first riser,… … Fig. 442. the left-hand pedestal, both on the plan and elevation. Amere inspection of the figure will be sufficient to show howthe shadow of the right-hand pedestal is obtained.
