AMEEICAlf HOUSE-CAEPENTER. 95 … Fig. 123. at Fig. 123. The several centres in rotation are at the anglesformed bj the heavy lines, as figured, 1, 2, 3, 4, 5, 6, &c. Theposition of these angles is determined by commencing at thepoint, 1, and making each heavy line one part less in lengththan the preceding one. ]^o. 1 is the…
