The American house carpenter: a treatise upon architecture, cornices and mouldings, framing, doors, windows and stairs. Together with the most important principles of practical geometry (1852)

Hatfield, R. G. (Robert Griffith), 1815-1879 · New York, J. Wiley · leaf 131

An illustration from The American house carpenter: a treatise upon architecture, cornices and mouldings, framing, doors, windows and stairs. Together with the most important principles of practical geometry, 1852, leaf 131
Fig. 141. Fig. 140. 235.— To describe the Grecian cavetto, {Fig. 140 and 141,)having the height and projection given, see Art. 118. a I \iw 1^ Wi V c … Fiff. 142. Fig. 143. 236.— To describe the Grecian cyma-recta. When the pro-jection is more than the height, as at Fig. 142, make a b equalto the height, and divide ah c d into 4 equal parallelograms;then proceed cis directed in note to Art. 118. When the projec-tion is less than the height, draw d…

Carpentry · Architecture

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
