The American house carpenter: a treatise upon architecture, cornices and mouldings, framing, doors, windows and stairs. Together with the most important principles of practical geometry (1852)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York, J. Wiley · leaf 147
will be the pressure, nnd vice versa. Hencetremendous strains m.ay be exerted by a comparatively smallweight. And it follows, therefore, that a piece of timber intend-ed for a strut or post, should be so placed that its axis may coin-cide, as near as possible, with the direction of the pressure.… … Fig. 183. FRAMING. 131 for the weight would be in that line. But, as it rarely occurs insystems of framing that weights can be supported by any singleresistance, they requiring generally two or more supports, (as inthe case of a roof supported by its rafters,) it becomes important,therefore, to…
Carpentry · Architecture
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
