The American house carpenter: a treatise upon architecture, cornices and mouldings, framing, doors, windows and stairs. Together with the most important principles of practical geometry (1852)

Hatfield, R. G. (Robert Griffith), 1815-1879 · New York, J. Wiley · leaf 218

An illustration from The American house carpenter: a treatise upon architecture, cornices and mouldings, framing, doors, windows and stairs. Together with the most important principles of practical geometry, 1852, leaf 218
door or window be placed at right angles to the face of thewall, the edges of the sojfif, or surface of the head, would bestraight, and its length be found by getting the stretch-out of the DOORS, WINDOWS, &C. 201 circle, {Art. 92 ;)but, when the jambs are placed obliquely to theface of the… … Fig. 252. 354.— To find the for?n of the soffit for circular window-heads^ when the light is received in an oblique direction. Leta b cdj {Fig. 252,) be the ground-plan of a given window, ande/a, a vertical section taken at right angles to the face of the jambs.From a, through e, draw ag, at right…

Carpentry · Architecture

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
