The American house carpenter: a treatise upon architecture, cornices and mouldings, framing, doors, windows and stairs. Together with the most important principles of practical geometry (1852)

Hatfield, R. G. (Robert Griffith), 1815-1879 · New York, J. Wiley · leaf 289

An illustration from The American house carpenter: a treatise upon architecture, cornices and mouldings, framing, doors, windows and stairs. Together with the most important principles of practical geometry, 1852, leaf 289
Fig. 333. 429.—Fig. 333 and 334 are examples of the Tuscan cornice.The manner of obtaining the shadows is evident. 272 A.MERICAN HOUSE-CARPENTER. … Fig. 334. 430.—Reflected light. In shading, the finish and Ufe of anobject depend much on reflected light This is seen to advantagein Fig. 330 and on the column in Fig. 332. Reflected rays arethrown in a direction exactly the reverse of direct rays ; therefore,on that part of an object which is…

Carpentry · Architecture

Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
