Fig. 53. 92, a.—Another method. Let a bf c, {Pig. 53,) be the givencircle. Draw the diameter, a c ; from d, the centre, and at rightangles to a c, draw d b ; join b and c ; bisect be at e; from rf,through e, draw df; then e/added to three times the diameter, PRACTICAL GEOMETRY. 29 will equal the… … Ti., given circle. Draw the diaaieter, b d ; upon 6, with the radius v»f the given circle, dcFcribe the arc, a e c ; join a and c, also a eind d, and c and d—and the triangle is completed. For the I;e*xagon : from a, also from c, through e, draw the lines, a f and eg; join a and b, b and c, c and/,…
