Hatfield, Robert Griffith, 1815-1879. [from old catalog] · New York & London, Wiley and Putnam · leaf 260
, at right angles to gp, and from c, draw c q, parallel to g-p ;make r q equal to h g at Fig. 296 ; joinp and q, and proceed asin the previous examples to find the face-mould, A. The jointof the face-mould, u v, will be more accurately determined byfinding the projection of the centre of the plan,… … Fig. 295. AMERICAN HOUSE-OARPENTER.
Carpentry · Architecture
