The American house-carpenter; a treatise on the art of building, and the strength of materials (1867)
Hatfield, R. G. (Robert Griffith), 1815-1879 · New York, J. Wiley · leaf 384
at right angles to gp, and from c, draw c q. parallel to gp ;make r q equal to A ^ at Fig. 327 ; joinp and q, and proceed asin the previous examples to find the face-mould, A. The jointof the face-mould, u v, will be more accurately determined byfinding the projection of thecentre of the plan, o,… … Tig. 326. 3T2 AMERICAN HOUSE ^ARPENTER,
Carpentry · Architecture
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
