American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions (1914)

Colvin, Fred H. (Fred Herbert), 1867-1965, Stanley, Frank A. (Frank Arthur), b. 1874 · New York : McGraw-Hill book company ; London : Hill · leaf 348

An illustration from American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions, 1914, leaf 348
ual.Consequently to determine the correct diameter of the piece to bemeasured, apply the gage as indicated in the sketch and deductone third of the total measurement. The use of this gage has a decided advantage over the old wayof soldering on a piece of metal opposite a tooth or boring out a… … TJ Illi! Fig. 8. — Measuring Three-Fluted Tools PRESS AND RUNNING FITS Parallel Press, Drive and Close Fits Table i, page 320, gives the practice of the C. W. Hunt Company,New York, for press, drive and close or hand J&ts for parallel shaftsranging between one and ten inches in diameter. In…

Machine-shop practice

Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
