American machinists' handbook and dictionary of shop terms : a reference book of machine shop and drawing room data, methods and definitions (1914)
Colvin, Fred H. (Fred Herbert), 1867-1965, Stanley, Frank A. (Frank Arthur), b. 1874 · New York : McGraw-Hill book company ; London : Hill · leaf 631
18. Arm shaft. 36. Arm-swinging handle. IQ. Arm ways. 37- Elevating lever. 20. Arm rack. 38. Clamping ring. 21. Saddle. 39- Clamping-ring handle. 22. Reversing lever. 40. Column. 2,S- Back-gear lever. 41. Column driving-miters 24. Head-swiveling worm. 42. Driving-shaft coupling. 2,S- Feed-trip… … DRILL PRESS —CINCINNATI MACHINETOOL COMPANY DRILLS — Continued 603 Drai Press — Parts of 1. Main driving gears, bevel. iS. Feed-change handle. 2. Back gears. 19. Sliding head. 3- Upper cone pulley. 20. Face of column. 4- Yoke to frame. 21. Back brace. 5- Feed gears. 22. Belt shifter. 6.…Machine-shop practice
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
