Gould, Lucius D., b. 1814. [from old catalog] · New York, A.J. Bicknell & co. · leaf 86
rallel to S 2 and S 3, cutting the major axis at thepoints required. The bevel, for the straight wood, is shown at S; for thecentre joint, at B. The mould, for the lower wreath, is shown at Fig. 4. Draw B C, equal toS C, Fig. 1, and B A, equal to S H, Fig. 3; set off each way from C, halfthe width… … I Plate 21 Exhibits the ground plan and elevation for a quarter circle of winders, and thestarting of t?ie return flight, from the spring of the cylinder; the wreath intwo To find the major axis, of the elliptic curve for the centre of the moulds,draw lines from A and L, Fig. 1, parallel to C P,…
Stair building
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
