American telegraphy and encyclopedia of the telegraph; systems, apparatus, operation (1909)
Maver, William, jr. [from old catalog] · New York, Maver publishing company · leaf 153
arts flowing through the shunt, and when the ^- shunt,namely, the shunt of highest resistance is used a -^jj part of the current flows inthe galvanometer coil, the other -^^ parts in the shunt. Consequently, any deflectionobtained when the ^ shunt is used is multiplied 10 times, for the reason… … practically lo times greater than that of the angle obtained when that shunt is used.Similarly, when the -^ shunt is employed, the deflection is multiplied loo times, andwhen the-g^ shunt is employed, looo times. On this account the various shuntsare sometimes termed the tenth, hundredth and one…
Telegraph
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
